Skid Steer Loaders 236D3

Product Specifications for 236D3

236D3 Standard Equipment

ELECTRICAL

• 12 volt Electrical System

• 80 ampere Alternator

• Ignition Key Start/Stop Switch

• Lights: Gauge Backlighting, Two Rear Tail Lights, Two Adjustable Front and Rear Halogen Lights, Dome Light

• Backup Alarm

• Heavy Duty Battery, 850 CCA

OPERATOR ENVIRONMENT

• Advanced Display with Rearview Camera: Full Color, 127 mm (5 in) LCD screen; Advanced Multi-operator Security System; On-screen Adjustments for Implement Response, Hystat Response and Creep Control

• Gauges: Fuel Level, Hour Meter

• Operator Warning System Indicators: Air Filter Restriction, Alternator Output, Armrest Raised/Operator Out of Seat, Engine Coolant Temperature, Engine Oil Pressure, Glow Plug Activation, Hydraulic Filter Restriction, Hydraulic Oil Temperature, Parking Brake Engaged, Engine Emission System

• Adjustable Vinyl Seat

• Fold In Ergonomic Contoured Armrest

• Control Interlock System, when operator leaves seat or armrest raised: Hydraulic System Disables, Hydrostatic Transmission Disables, Parking Brake Engages

• ROPS Cab, Open, Tilt Up

• FOPS, Level I

• Top and Rear Windows

• Floor Mat

• Interior Rearview Mirror

• 12 volt Electric Socket

• Horn

• Hand (Dial) Throttle, Electronic

• Adjustable Joystick Controls

• Anti-theft Security System with 6-button Keypad

• Storage Compartment with Netting

POWER TRAIN

• Cat C3.3B, Turbo Diesel Engine, Meeting Tier 4 Final and Stage V Emission Standards

• Air Cleaner, Dual Element, Radial Seal

• S·O·SSM Sampling Valve, Hydraulic Oil

• Filters, Cartridge-type, Hydraulic

• Filters, Canister-type, Fuel and Water Separator

• Radiator/Hydraulic Oil Cooler (side-by-side)

• Spring Applied, Hydraulically Released Parking Brakes

• Hydrostatic Transmission

• Four Wheel Chain Drive

OTHER

• Engine Enclosure, Lockable

• Extended Life Antifreeze, –36° C (–33° F)

• Machine Tie Down Points (6)

• Support, Lift Arm

• Hydraulic Oil Level Sight Gauge

• Radiator Coolant Level Sight Gauge

• Radiator, Expansion Bottle

• Cat ToughGuard™ Hose

• Auxiliary, Hydraulics, Continuous Flow

• Heavy Duty, Flat Faced Quick Disconnects with Integrated Pressure Release

• Split D-Ring to Route Work Tool Hoses Along Side of Left Lift Arm

• Electrical Outlet, Beacon

• Belly Pan Cleanout

• Variable Speed Demand Fan

• Product Link™ PL240, Cellular

MANDATORY EQUIPMENT

• Hydraulics, Standard or High Flow

• Quick Coupler, Mechanical or Powered

• Highly Visible Seat Belt, 50 mm (2 in) or 75 mm (3 in)

• EU Preparation Package

• Power Train: One Speed, One Speed with Speed Sensitive Ride Control, Two Speed or Two Speed with Speed Sensitive Ride Control

• Tires, 10 × 16.5 or 12 × 16.5

• PERFORMANCE PACKAGES:
  – Performance Package H1: Standard Flow Hydraulics (No Self Level)
  – Performance Package H2: Standard Flow Hydraulics, Dual Direction Electronic Self Level (Raise and Lower), Work Tool Return to Dig, Work Tool Positioner, and Electronic Snubbing (Raise and Lower)
  – Performance Package H3: High Flow Hydraulics, Dual Direction Electronic Self Level (Raise and Lower), Work Tool Return to Dig, Work Tool Positioner, and Electronic Snubbing (Raise and Lower)

• COMFORT PACKAGES:
  – Open ROPS (C0): Static Seat (No Foot Throttle, Headliner, Heater or Door)
  – Open ROPS (C1): Foot Throttle, Headliner, Cup Holder, and choice of Seat (Mechanical Suspension or High Back, Heated, Air Ride Seat) (No Heater or Door)
  – Enclosed ROPS with Heater (C2): Foot Throttle, Headliner, Heater and Defroster, Side Windows, Cup Holder, Radio Ready, choice of Seat (Mechanical Suspension or High Back, Heated, Air Ride Seat) and Door (Glass or Polycarbonate)
  – Enclosed ROPS with A/C (C3): C2 + Air Conditioner

236D3 Optional Equipment

OPTIONAL EQUIPMENT

• Hand-Foot Style Controls

• External Counterweights

• Beacon, Rotating

• Engine Block Heater – 120V

• Oil, Hydraulic, Cold Operation

• Paint, Custom

• Product Link PL641, Cellular

• Bluetooth® Radio with Microphone (AM/FM/Weather Band Receiver with USB and Auxiliary Input Jack)
