Angle Blades - Compact Products 1829 mm (72 in)

Request A Price Shop Now

Key Specs

Blade Width: 72 in; 1829 mm

Width - Fully Angled: 66.3 in; 1685 mm

Maximum Blade Angle - Right/Left of Center: 30 degrees; 30 degrees

1829 mm (72 in)
Change model

Overview

Robust, high capacity design for moving dirt, gravel, livestock waste and snow.

Features At A Glance

Displaying 1-6 of 10

Application

Designed for moving dirt, gravel, livestock waste and snow. Also ideal for finish grade work in construction and landscaping applications.

Two-Way Blade

Two-way blade can be operated with the blade locked for aggressive dozing or with spring-loaded trip engaged for pushing snow or livestock waste.

Angle Range

Blade angles +/- 30 degrees to assist in various tasks.

Curved Moldboard

Curved moldboard with standard reversible/replaceable bolt-on, hardened DH-2 steel cutting edge delivers long life and high performance.

Adjustable Skid Shoes

Adjustable skid shoes reduce the chances of gouging plowed surface and allow for improved operator control and maintains a constant cutting-edge depth.

Spherical Rod Eye Cylinder

Spherical rod eye cylinder adds another degree of movement to jointed section for better impact protection.

Designed for moving dirt, gravel, livestock waste and snow. Also ideal for finish grade work in construction and landscaping applications.

Two-way blade can be operated with the blade locked for aggressive dozing or with spring-loaded trip engaged for pushing snow or livestock waste.

Blade angles +/- 30 degrees to assist in various tasks.

Curved moldboard with standard reversible/replaceable bolt-on, hardened DH-2 steel cutting edge delivers long life and high performance.

Adjustable skid shoes reduce the chances of gouging plowed surface and allow for improved operator control and maintains a constant cutting-edge depth.

Spherical rod eye cylinder adds another degree of movement to jointed section for better impact protection.

Four pre-loaded springs provide appropriate force with spring-loaded trip engaged. Springs can be removed individually to accommodate a lighter trip.

Allows for proper ground interface with different hinge pin heights on compact wheel loaders, skid steer and compact track loaders.

Optional snow kit with heavy-duty guard assembly, two edge markers and mounting hardware.

Optional bolt-on, non-metallic edge reduces surface scratches or marring of concrete and asphalt surfaces.

Product Specifications for 1829 mm (72 in)

Blade Width	72 in 1829 mm
Width - Fully Angled	66.3 in 1685 mm
Maximum Blade Angle - Right/Left of Center	30 degrees 30 degrees
Blade Height	24.2 in 614 mm
Cutting Edge Width	74.5 in 1893 mm
Length	29.6 in 753 mm
Weight	690 lb 313 kg
Cutting Edge Thickness	0.6 in 16 mm
Optimal Hydraulic Flow	42-86 L/min (11-23 gpm) 42-86 L/min (11-23 gpm)
Optimal Hydraulic Pressure	145-235 bar (2100-3400 psi) 145-235 bar (2100-3400 psi)
Required Hydraulics	Standard Flow Standard Flow
Interface Type	Skid Steer Coupler Skid Steer Coupler
