Pickup Brooms BP25, 12V

Request A Price Shop Now

Key Specs

Overall Width: 106.3 in; 2700 mm

Sweeping Width: 98.4 in; 2500 mm

Brush Diameter: 27.6 in; 700 mm

BP25, 12V
Change model

Overview

Cat® Pickup Brooms collect dirt and debris from a variety of surfaces.

Features At A Glance

The BP22 is powered by one hydraulic motor, the BP25 is powered by two hydraulic motors. Each motor is mounted to protect them from damage.

Parking supports provide stable and secure parking of the broom when not in use.

Pickup Brooms incorporate a unique suspension system to eliminate the need for support wheels. This allows the broom to float freely over the work surface and ensures proper bristle contact from the initial setting.

Leveling indicator allows operator to conveniently see the level of the broom from the cab during operation.

Pickup Brooms include a large hopper for greater productivity and easy removal and emptying.

The BP22 and BP25 both feature a 400 liter (106 gallon) capacity integrated water tank.

Water sprinkler kit helps reduce the amount of airborne dust during sweeping operations.

Tool Mounted Operation and Maintenance Manual (OMM) Holder

Tool mounted and sealed from the elements, this holder includes all of the operation manuals and maintenance guides required for proper operation of the work tool.

Cat® Pickup Brooms come standard with replaceable polypropylene sections. Convoluted bristle sections can be converted to all wire or 50/50 poly and wire for special applications.

Product Specifications for BP25, 12V

Overall Width	106.3 in 2700 mm
Sweeping Width	98.4 in 2500 mm
Brush Diameter	27.6 in 700 mm
Required Hydraulics	3rd Valve 3rd Valve
Height	51.2 in 1300 mm
Length	72 in 1830 mm
Weight	1433 lb 650 kg
Optimal Hydraulic Flow	40-150 L/min (11-40 gpm) 40-150 L/min (11-40 gpm)
Optimal Hydraulic Pressure	150-260 bar (2176-3771 psi) 150-260 bar (2176-3771 psi)
Motor Displacement	11.9 in³/rev 195 cm³/rev
Brush Speed at Maximum Flow	385 RPM 385 RPM
Hopper Capacity	0.9 yd³ 0.66 m³
Voltage	12V 12V
Drive Method	Direct Drive Direct Drive
Interface Type	Requires Hook Group Requires Hook Group
