Heavy Duty Buckets - Mini Excavator 457 mm (18 in), 82 L (2.9 ft3), Pin On, 40 mm (1.6 in)

Name: 457 mm (18 in), 82 L (2.9 ft3) Pin On Heavy Duty Bucket With 40 mm (1.6 in) Pin Bores
Brand: Cat

New Used Rental

Request A Price Shop Now

Key Specs

Width: 18 in; 457 mm

Capacity: 2.9 ft³; 82.09 l

Weight: 180.8 lb; 82 kg

457 mm (18 in), 82 L (2.9 ft3), Pin On, 40 mm (1.6 in)
Change model

Overview

High strength buckets designed for maximum performance and value over a broad range of applications.

Features At A Glance

Displaying 1-6 of 4

Application

Cat® Heavy Duty Buckets are well suited for semi-rocky soil or where hard bank material must be broken out and removed. Ideal for utility trenching, digging footings, back-filling and general excavating in construction, landscaping and utility applications.

Bucket Design

Formed back wrapper design enhances bucket loading ability and production.

Superior Bucket Fill

Optimum wrapper angle and no sharp corners promote superior bucket fill and reduce material packing.

Bucket Shape

Enhanced bucket shape allows material to flow more easily. Tapered bucket sidewalls allow for easy dumping of sticky material.

Product Specifications for 457 mm (18 in), 82 L (2.9 ft3), Pin On, 40 mm (1.6 in)

Width	18 in 457 mm
Capacity	2.9 ft³ 82.09 l
Weight	180.8 lb 82 kg
Base Edge Thickness	0.8 in 20 mm
Tip Radius	28 in 710 mm
Interface Type	Pin On Pin On

Product Specifications for 457 mm (18 in), 82 L (2.9 ft3), Pin On, 40 mm (1.6 in)

Download Print

Width	18 in 457 mm
Capacity	2.9 ft³ 82.09 l
Weight	180.8 lb 82 kg
Base Edge Thickness	0.8 in 20 mm
Tip Radius	28 in 710 mm
Interface Type	Pin On Pin On
