Controls MPC100

Name: Marine Propulsion Control System (MPC100)
Brand: Cat

Request A Price Find Dealer

MPC100
Change model

Overview

The Cat® MPC100 is the new Propulsion Control System solution designed for commercial vessels and yachting.
It is the ideal control system for single and twin-propeller applications, providing the captain reliable control of his vessel at any given time even in the harshest marine environments. Particular attention has been paid to the design and ergonomics, which not only adapts to a luxurious environment but also provides ease of operation and unmatched user experience. MPC100 is featuring extensive capabilities for integration into the vessel’s ecosystem.

Features At A Glance

Displaying 1-6 of 10

Key Features and Benefits

Supports 12 and 24VDC powered applications
Available for all electronically controlled Cat Marine Propulsion Engines
Compatible with all major Marine transmissions
Control from up to 8 Command Stations
Built-in Control of the Engine, Transmission incl. Trolling Valve
Mode Selector incl. Warm-up, Trolling, Advanced Trolling, Slow Vessel and Cruising Modes
Synchronization Mode for Twin Propeller Operation using Single Lever
Engine Start Interlocks
Highly configurable for multiple powertrain configurations
Easy Plug & Play Installation supported by Cat ET (Electronic Technician)
Optional backup control panel

Ergonomic handle and lever

Comfortable to grip in all ways and directions

Exchangeable handle

Top surface of handle is possible to change to fit the environment and helm design

Safe operation

Buttons are recessed to prevent unintentional actuation

Clear haptics

Rubber buttons with metal domes give a distinct and clear haptic feedback

Small, rectangular footprint

Requires less helm panel real estate and facilites installation

Supports 12 and 24VDC powered applications
Available for all electronically controlled Cat Marine Propulsion Engines
Compatible with all major Marine transmissions
Control from up to 8 Command Stations
Built-in Control of the Engine, Transmission incl. Trolling Valve
Mode Selector incl. Warm-up, Trolling, Advanced Trolling, Slow Vessel and Cruising Modes
Synchronization Mode for Twin Propeller Operation using Single Lever
Engine Start Interlocks
Highly configurable for multiple powertrain configurations
Easy Plug & Play Installation supported by Cat ET (Electronic Technician)
Optional backup control panel

Comfortable to grip in all ways and directions

Top surface of handle is possible to change to fit the environment and helm design

Buttons are recessed to prevent unintentional actuation

Rubber buttons with metal domes give a distinct and clear haptic feedback

Requires less helm panel real estate and facilites installation

Resisting weather challenges

Fits with other components in the helm and makes the conrol blend in

Consistent with other components in a glass bridge helm

Only shows the information that is relevant and vital at each specific time

Standard Equipment Optional Equipment

MPC100 Standard Equipment

MCL100 - Integrated Marine Control Lever Head

features a compact design with an integrated mode selector. It includes a built-in display that utilizes a dynamic user interface to enhance the user experience. Additionally, the lever head is equipped with general alarm status indicators

MPL100 - MARINE PALM BEACH LEVER ASSEMBLY

Interface unit to the larger side-mounted handles

MCD100 - Marine Control Display

Multi-purpose control device with integrated backup control unit used for the palm beach lever head integration point as well as the interface to the advanced lever head

MCP100/300 - Marine Control Processor

Redundant control processor unit for controlling single or twin-powertrain configurations, incl. engine transmissions and trolling valves

Harnessing

Standardized control and engine room harnessing available in various lengths

MPC100 Optional Equipment

MML100 - Advanced Lever

Featuring cutting-edge built-in redundant sensor packages, this motorized lever offers seamless follow-up control, enabling exquisite customization tailored to your unique needs

CMD - Cat Marine Displays

CMD5, CMD8, and CMD13 with easy access to operating data and alarm notification for engine and powertrain control systems
