Cat® Tiltrotators help you maneuver obstacles in your work area without the need for repositioning your machine.
Features At A Glance
Displaying 1-6 of 10
Complete 360 Degree Rotation
Provides optimal control of your work tools to provide greater flexibility.
Integrated Central Lubrication System
A single point of entry for grease allows the entire unit to be greased quickly and easily.
TRS8 Positioning System
Upgraded software informs the operator of the attachments position via standard equipped monitoring sensors.
Oil Filled Gearbox
A maintenance free solution that more effectively distributes heat, providing better lubrication than grease.
Heavy Duty Worm Gear
Worm gear box with high rotation torque and self locking ability allows digging in all directions with full power, allowing the gear to accept the maximum machine forces and split the load through the entire TRS construction.
Double Acting Cylinders with Load Hold Valves
Valves sustain holding pressures and prevent cylinders movement under load constraints required by directives.
Visual Verification Indicator
The visual verification indicator allows the operator to visibly confirm, from the cab, that the coupler has successfully locked the attachment into place properly.
Optional Grapple Attachment
Used to pick up objects such as pipe and debris.
Locking Control System (LCS)
LCS incorporates an electronic position sensor integrated into the quick coupler hydraulic cylinder. This sensor provides precise and reliable input to an electronic processor mounted inside the quick coupler. This microprocessor provides digital communication to the Next Generation MHE machine Electronic Control Module (ECM) by way of an electrical harness. This data is then displayed on the operators display screen, and will provide audible indications when that locking status changes.
LED Light
Used for visibility when engaging and disengaging a tool underneath the TRS8.
Features At A Glance
Provides optimal control of your work tools to provide greater flexibility.
A single point of entry for grease allows the entire unit to be greased quickly and easily.
Upgraded software informs the operator of the attachments position via standard equipped monitoring sensors.
A maintenance free solution that more effectively distributes heat, providing better lubrication than grease.
Worm gear box with high rotation torque and self locking ability allows digging in all directions with full power, allowing the gear to accept the maximum machine forces and split the load through the entire TRS construction.
Valves sustain holding pressures and prevent cylinders movement under load constraints required by directives.
The visual verification indicator allows the operator to visibly confirm, from the cab, that the coupler has successfully locked the attachment into place properly.
Used to pick up objects such as pipe and debris.
LCS incorporates an electronic position sensor integrated into the quick coupler hydraulic cylinder. This sensor provides precise and reliable input to an electronic processor mounted inside the quick coupler. This microprocessor provides digital communication to the Next Generation MHE machine Electronic Control Module (ECM) by way of an electrical harness. This data is then displayed on the operators display screen, and will provide audible indications when that locking status changes.
Used for visibility when engaging and disengaging a tool underneath the TRS8.
Product Specifications for TRS8, Pin On (Pin Grabber)/S45, 10 Ton Mini Excavators
Machine Class
10 Ton Mini Excavators10 Ton Mini Excavators
Weight
712.1 lb323 kg
Interface Options: Top-Bottom
Pin On (Pin Grabber Coupler) / S45 CouplerPin On (Pin Grabber Coupler) / S45 Coupler
Overall Height
37.7 in957 mm
Length
26 in660 mm
Overall Width
26.7 in678 mm
Rotation Speed
7 Seconds per 1 full rotation7 Seconds per 1 full rotation
Tilt Angle Range
40° Left/Right40° Left/Right
Maximum Bucket Capacity
17.7 ft³500 l
Maximum Bucket Width
59.1 in1500 mm
Optimal Hydraulic Flow
45-75 L/min (12-20 gpm)45-75 L/min (12-20 gpm)
Maximum Operating Pressure
3625.9 psi25000 kPa
Required Hydraulics
1st Auxiliary1st Auxiliary
Tilting Torque
19545.4 lb/ft26500 N·m
Turning Torque
2876.5 lb/ft3900 N·m
Compatibility
Only compatible with the following Mini Excavator model serial number prefixes: 310 (GWT 1 & up)Only compatible with the following Mini Excavator model serial number prefixes: 310 (GWT 1 & up)
Product Specifications for TRS8, Pin On (Pin Grabber)/S45, 10 Ton Mini Excavators
Pin On (Pin Grabber Coupler) / S45 CouplerPin On (Pin Grabber Coupler) / S45 Coupler
Overall Height
37.7 in957 mm
Length
26 in660 mm
Overall Width
26.7 in678 mm
Rotation Speed
7 Seconds per 1 full rotation7 Seconds per 1 full rotation
Tilt Angle Range
40° Left/Right40° Left/Right
Maximum Bucket Capacity
17.7 ft³500 l
Maximum Bucket Width
59.1 in1500 mm
Optimal Hydraulic Flow
45-75 L/min (12-20 gpm)45-75 L/min (12-20 gpm)
Maximum Operating Pressure
3625.9 psi25000 kPa
Required Hydraulics
1st Auxiliary1st Auxiliary
Tilting Torque
19545.4 lb/ft26500 N·m
Turning Torque
2876.5 lb/ft3900 N·m
Compatibility
Only compatible with the following Mini Excavator model serial number prefixes: 310 (GWT 1 & up)Only compatible with the following Mini Excavator model serial number prefixes: 310 (GWT 1 & up)
See how TRS8, Pin On (Pin Grabber)/S45, 10 Ton Mini Excavators compares against frequently compared products.
Tilt Rotate Systems
Selected
TRS8, Pin On (Pin Grabber)/S45, 10 Ton Mini Excavators
Machine Class
10 Ton Mini Excavators
10 Ton Mini Excavators
Weight
712.1 lb
323 kg
Interface Options: Top-Bottom
Pin On (Pin Grabber Coupler) / S45 Coupler
Pin On (Pin Grabber Coupler) / S45 Coupler
New
Tilt Rotate Systems
TRS8, Pin On (Pin Grabber)/Pin Grabber, 7-9 Ton Mini Excavators
Machine Class
7-9 Ton Mini Excavators
7-9 Ton Mini Excavators
Weight
694.5 lb
315 kg
Interface Options: Top-Bottom
Pin On (Pin Grabber) Coupler / Pin Grabber Coupler
Pin On (Pin Grabber) Coupler / Pin Grabber Coupler
