MP318 Universal Jaw

Multi-Processor with Universal Jaws MP318 Universal Jaw

Request A Price Find Dealer

Key Specs

Cycle Time - Open
1.6 s
1.6 s
Excavator Minimum
18 tons
18 tons
Cycle Time - Close
1 s
1 s

Overview

Cat® Multi-Processors accept multiple interchangeable jaws for a wide range of demolition tasks. Faster cycle times get your jobs done quicker. Greater power means taking on bigger jobs. Quick jaw change gives you the right tool for the task at hand, without slowing you down. All built on a durable, easy to maintain platform.

Features At A Glance

Displaying 1-6 of 4

Cat

Cycle Times are 50 Percent Faster

  • New speed booster technology dynamically shifts hydraulic force from speed to boost mode, automatically as you operate.
  • You'll spend less time waiting for the jaw to open or close to contact, as the speed valve automatically adjusts to fast flow when there's no load.
  • Maximum crushing/cutting force is applied as soon as the jaw contacts material.
Cat

Up to 19 Percent More Force

  • Process more per hour, ship more per shift, make more money every day. Speed booster magnifies hydraulic force when the jaw contacts material, quickly making the cut.
  • Mount more power even on smaller excavators. Compact design keeps the center of gravity as close as possible to the machine.
  • Get maximum performance and total support with a complete Cat demolition solution. Programs for the MP are built into the Next Gen Cat operator display. Single point of support your entire system by your local Cat dealer.
Cat

Change Jaw in 15 Minutes

  • Innovative jaw locking enables a single operator to easily change jaws in 15 minutes or less. Requires only standard hand tools.
  • Simple and safe jaw changes are part of the design. Every jaw sits stable, even on the roughest work site, on the included jaw stand.
  • MP318 accepts these jaw types:
    • Concrete Cutter - outer jaw cracks concrete; inner shear jaw cuts steel
    • Demolition - opens wide to crack the largest concrete structures
    • Pulverizer - crushes concrete, separating the rebar
    • Shear - cuts structural steel, pipe, and cable
    • Universal - innovative design cuts steel crushes concrete
Cat

Durable and Maintainable

  • Protect your investment and maintain performance, quickly and economically. Jaws are protected with easily changed, individually replaceable wear parts.
  • Get more production time per cutter before replacement. Most cutting blades can be flipped in two ways, to use four different cutting edges.
  • Even when deep into debris, the cylinder rod is armored to prevent damage and the main cylinder body is protected inside the housing.

Product Specifications for MP318 Universal Jaw

Download Print
Cycle Time - Open 1.6 s 1.6 s
Cycle Time - Close 1 s 1 s
Crushing Force - Primary Cutter 299.1 Sh Ton 2661 kN
Crushing Force - Cutter Tip 167.4 Sh Ton 1489 kN
Crushing Force - Tooth Tip 96.1 Sh Ton 855 kN
Excavator Minimum 18 tons 18 tons
Excavator Maximum 25 tons 25 tons
Jaw Circuit - Max. Oil Pressure 4786 psi 33000 kPa
Jaw Circuit - Max. Oil Flow 39.6 gpm 150 L/min
Rotation Circuit - Max. Oil Pressure 2031 psi 14000 kPa
Rotation Circuit - Max. Oil Flow 10.6 gpm 40 L/min
Jaw Depth 22.2 in 565 mm
Cutter Length 15.7 in 400 mm
Jaw Opening - Maximum 18.2 in 462 mm
Jaw Width - Fixed 15 in 380 mm
Jaw Width - Moveable 8.4 in 214 mm
Length 78.9 in 2003 mm
Height 50.2 in 1274 mm
Width 31.2 in 793 mm
Weight - Housing, Jaw and Bracket 4351.9 lb 1974 kg
Weight - Jaw Only 1682.1 lb 763 kg
