Key Specs

Blows per Minute: 450 to 800; 450 to 800

Minimum Operating Weight: 3098 lb; 1405 kg

Rated Flow - Minimum: 24 gpm; 90 L/min

H115 GC S
Change model

Overview

Cat® H115 GC S hammers are designed for durability in rock breaking and concrete demolition. With powerful hydraulics and quick access to maintenance areas, Cat H115 GC S hammers help increase overall productivity and reduce maintenance costs. Cat H115 GC S hammers are a versatile solution for many applications, including road construction, trenching, and demolition.

Features At A Glance

Automatic shutoff offers blank firing protection by stopping the piston when there is no material under the tool to help extend the life of the hammer.
Manually adjust the piston speed by choosing between high piston speed or maximum power to help increase efficiency and production on the job site.
The standard silencing feature allows you to use a GC S hammer on job sites in noise sensitive areas like neighborhoods or near hospitals where noise is regulated.

The internal buffering system helps reduce machine vibration and increase noise suppression.
Simple hammer design for easy maintenance and faster rebuilds to help lower owning and operating costs.
Critical hydraulic components are shielded from damage inside the housing, helping decrease downtime on the job site.

Standard onboard autolube provides continuous greasing as the hammer runs, eliminating the need for manual greasing.
The slip-fit lower bushing allows for easy replacement in the field, helping reduce service time.
Verify the gas charge of the hammer without removing it from your machine.
Quick and easy access to maintenance areas helps make hammer maintenance simple.

Boost Efficiency and Productivity with Integrated Technologies

Never waste time looking for your attachments again. Cat asset tracking is available on all hammers.
Track your entire fleet of attachments and machines from one source. Hammers with asset tracking can be viewed within VisionLink®.
Keep your assets secure. Hammers with an asset tracker send an alert if they leave an easy-to-set-up site boundary.

Product Specifications for H115 GC S

Blows per Minute	450 to 800 450 to 800
Minimum Operating Weight	3098 lb 1405 kg
Rated Flow - Minimum	24 gpm 90 L/min
Rated Flow - Maximum	32 gpm 120 L/min
Minimum Operating Pressure	2175 psi 15000 kPa
Maximum Operating Pressure	2465 psi 17000 kPa
Tool Shaft Diameter	4.7 in 120 mm
Minimum Carrier Weight	28660 lb 13 t
Maximum Carrier Weight	39683 lb 18 t

Product Specifications for H115 GC S

Download Print

Blows per Minute	450 to 800 450 to 800
Minimum Operating Weight	3098 lb 1405 kg
Rated Flow - Minimum	24 gpm 90 L/min
Rated Flow - Maximum	32 gpm 120 L/min
Minimum Operating Pressure	2175 psi 15000 kPa
Maximum Operating Pressure	2465 psi 17000 kPa
Tool Shaft Diameter	4.7 in 120 mm
Minimum Carrier Weight	28660 lb 13 t
Maximum Carrier Weight	39683 lb 18 t
